INITIAL SET-UP
MAINS CONNECTION
Your unit comes with one power adaptor (input: 220V-240V/50Hz ,output :12V 1A). Connect
your unit to a mains voltage via the power adaptor.
AMPLIFIER CONNECTION
Whilst you can listen to your new turntable using the built-in speakers, you may wish to
connect it to your existing Hi Fi system. Connect the audio plugs to the AUX input on your
mixer or amplifier using an RCA cable (not supplied).
 Red plug into R/H channel input.
 White plug into L/H channel input.
Playing a record
 Place the record on the turntable. If required, do not forget to place the adaptor on the record
spindle.
 Choose the desired playing speed using the speed selection switch between 33.3, 45 and 78rpm.
 Turn on the Rotary Power Switch, note that this also controls volume.
 Release the tone arm lock.
 Raise the arm with your hand lightly.
 Place the stylus vertically over the first track of the record, the turntable will start turning
automatically.
 Lower the stylus slowly onto the record to play.
 When a record comes to the end, the turntable will stop automatically if the auto-stop switch
is in the ON position. If the switch is in the off position then it will keep revolving until the tone
arm is returned to the tone arm rest.
 Lift up the tone arm and put it on the rest when finished.
 Replace the protective cap on the stylus and close the tone arm lock.
 Turn off the power at mains.
Connect to Bluetooth devices
Play from Bluetooth device:
1. Turn the AUTO STOP ON/OFF to “ON”.
2. Put the tonearm at the rest position. Then you will hear a beep sound.
3. Then, activate the Bluetooth function in your Bluetooth device (such as Mobile Phone or
tablet). The device will begin to automatically search for available nearby Bluetooth devices
to pair with.
4. Once the turntable is detected, your Bluetooth device will show “TTD109SP” on the list
of nearby devices. Select it for pairing. Wait a few seconds and your Bluetooth device
will list it as connected.
5. Now you can start to play music on your Bluetooth device.
