Teac w-865r User Manual

4
Table of Contents
Thank you for choosing TEAC. Read this manual carefully
to get the best performance from this unit.
Before Use
Read this before operation
< As the unit may become warm during operation, always leave
sufficient space around the unit for ventilation.
< The voltage supplied to the unit should match the voltage as
printed on the rear panel. If you are in any doubt regarding
this matter, consult an electrician.
<
Choose the installation location of your unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Avoid
locations subject to vibrations and excessive dust, heat, cold
or moisture.
<
Do not place the unit on any other electronic components.
<
Do not open the cabinet as this might result in damage to the
circuitry or electrical shock. If a foreign object should fall into
the unit, contact your dealer or service company as soon as
possible.
<
When removing the power plug from a wall outlet, always
pull directly on the plug. Do not pull on the line cord.
< Do not attempt to clean the unit with chemical solvents as
this might damage the finish. Use a clean, dry, lint-free cloth.
< Keep this manual in a safe place for future reference.
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Handling Cassette Tapes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the Remote Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . 7
Identifying the Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Playback (either TAPE I or TAPE II) . . . . . . . . . . . . . . . . . . . . . . 11
Continuous Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Blank Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Song Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Intro Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Recording (either TAPE I or TAPE II) . . . . . . . . . . . . . . . . . . . . . 16
Mic Mixing Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Continuous Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Dubbing (from TAPE I to TAPE II). . . . . . . . . . . . . . . . . . . . . . . 20
Parallel Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Editing during Dubbing (only at normal speed) . . . . . . . . . . . . 21
Synchro Reverse Dubbing (from TAPE I to TAPE II) . . . . . . . . . . 22
Timer-Controlled Playback and Recording . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Teac w-865r Specifications

General

Built-in microphone	No
Reverse	Yes
Number of decks	2 deck(s)
Product color	Black
Output power description	120V AC, 60Hz

Weight and Dimensions

Weight	4000 g
Dimensions (WxDxH)	435 x 127 x 292 mm
