Team C Hyde - Page 11

31
17
T02081 3x7x0.8 Washer
T02083 M3x8 Screw T02082 M3x5 Screw
TG2038 M3x3 Screw
………………2
……………2
…………1
………2
L
R
Assemble left and rear sides the same way
3
2
1
3
1
2
Assemble in the specified order
1
2
3
4
5
Motor
T02081
TG2038
T02082
T02120
30
L
R
T02084 M3 Nylon Nut
…………2
……2
T02082 M3x15 Screw
Rear Suspension
T02083
Long
長
T02082
T02084
