tecbot S1 Series - Page 9

5
07 Contact point for charging dock
08 ToF
sensor
09 Driving wheel
10 Edge-cleaning brush
11 Battery cover
12 Wheel
13 ToF optical sensor
14 V-shaped brush main cover
15 V-shaped brush
16 Dust box or water tank
10
15
10
11
08
12
14
12
13
08
08
16
07 0709
