1. 3(8%B9)I8;B(!
1.1 3(8%B9)I8;B(!8B!+,-+./0-1234!
The!TL-TP70-HDIR!is!an!ultra!thin!design!extender!set!consisting!of!a!transmitter!and!a!receiver.!
Using!HDBaseT!technology,!the!set!transmits!a!1080p!signal!to!the!receiver!up!to!70m!via!a!
shielded!Cat5e/Cat6!cable.! ! ! Bi-directional!IR!communication!is!included!to!allow!control!of!
an!IR!source!or!display.!PoC!power!allows!you!to!connect!the!power!supply!at!either!the!
transmitter!or!the!receiver!to!power!both!units.!Th e!set!also!sup p orts!A RC,!which!ena bles !
audio!up!streaming!from!display!to!an!audio!system!using!either!HDMI!or!the!coax!digital!
output.!
!
1.2 K$'8)%$#!
l HDMI1.4!compliant,!supports!resolutions!up!to!4Kx2K!
l Maximum!transmission!distance!is!70m!for!1080p!and!40m!for!4Kx2K!over!a!single!shielded!
CAT5e/CAT6!cable!
l High!Bandwidth:!10.2Gps.!
l Compliant!with!HDCP1.4!
l Uses!HDBaseT!technology!for!reliability!and!features!
l Supports!bi-directional!PoC!
l Supports!ARC!on!HDMI!or!coax!digital!output!
l Bi-directional!IR!control!
!
1.3 .'IJ'?$!,;#8!
² 1!x!TL-TP70-HDIR!(including!TX!and!RX)!
² 4!x!Mounting!Brackets!
² 4!x!Screws!
² 8!x!Rubber!Feet!
² 1!x!Power!Adapter!(DC!12V!1A)!
² 1x!IR!Emitter!(5V)!
² 1!x!IR!Receiver!(5V,!with!carrier)!
² 1!x!User!Manual!
&
Please!confirm!if!the!product!and!the!accessories!are!all!included,!if!not,!please!contact!
the!dealer.!
