TechLogix Networx TL-TP70-HDIR - 2 Panel Description; Hdbaset Transmitter; 7 After-Sales Service

2!
www.tlnetworx.com,
+,-+./0-1234! "#$%! &'()'*
2. .'($*!2$#I%;S8;B(!
2.1 12Q'#$+!+%'(#5;88$%!
!
K;?)%$!T-!E!.'($*!2$#I%;S8;B(!BH!+U!
OBR!
O'5$!
2$#I%;S8;B(!
!
LINK!
HDBT!Link!status!indicator,!lights!when!the !transmitter!&!receiver!are!linked!and!
communicating!
!
HDCP!
HDCP!compliant!indicator!
Ø Lights!when!input!signal!is!HDCP!encrypted!
Ø Blinks!when!the!input!signal!is!not!HDCP!encrypted!
Ø Turns!off!when!there!is!no!input!
!
Power!
Illuminates!red!when!the!unit!is!powered!on!
!
ARC!
Output!port!for!ARC!audio!
!
IR!IN!
Connect!the!included! 5V !IR!Receiver!(with!carrier)!to!receive!infrared!signal,!it!w ill!
output!at!the!RX!IR!OUT!
!
IR!OUT!
Connect!the!included!5V !IR ! Em itter!and!attach!to!the!IR!window!of!the!device!you!
wish!to!control.!
!
HDMI!IN!
Connect!HDMI!source!
!
TP!OUT!
Connect!to!the!TP!IN!socket!on!the!HDBaseT!Receiver!via!shielded!CAT5e/!CAT6!
cable,!supports!bi-directional!PoC!
!
DC!12V!
Insert!the! DC!12V!power!adapter!here!(optionally!connect!to!the!RX!–!only!one!
unit!needs!power!connected).!
!
ARC!Switcher!
Dip!switch!for!ARC!mode!(see!page!5).!
!
TX
HDCPLINK
Front
Rear
Bottom
On
Off
1 2
1
0
ON
1
2
ARC MODE
