2.2 12Q'#$+!4$I$;@$%!
!
K;?)%$!T-!T!.'($*!2$#I%;S8;B(!BH!4U!
OBR!
O'5$!
2$#I%;S8;B(!
!
LINK!
HDBT!Link!status!indicator,!lights!whe n!the !transmitter!&!receiver!are!linked!and!
communicating!
!
HDCP!
HDCP!compliant!indicator!
Ø Lights!when!input!signal!is!HDCP!encrypted!
Ø Blinks!when!the!input!signal!is!not!HDCP!encrypted!
Ø Turns!off!when!there!is!no!input!
!
Power!
Illuminates!red!when!the!unit!is!powered!on!
!
IR!IN!
Connect!the!included! 5V ! IR! Receiver!(with!carrier)!to!receive!infrared!signal,!it! w ill!
output!at!the!RX!IR!OUT!
!
IR!OUT!
Connect!the!included!5V !IR ! Em itter!and!attach!to!the!IR!window!of!the!device!you!
wish!to!control.!
!
HDMI!OUT!
Connect!to!an!HDMI!display!
!
TP!IN!
Connect!to!the!T P! OUT ! socket!on! the!HDBaseT!Transmitter!via!shielded!CAT5e/!
CAT6!cable,!supports!bi-directional!PoC.!
!
DC!12V!
Insert!the! DC!12V!power!adapter!here!(optionally!connect! to!the!T X! –!only!one!
unit!needs!power!connected).!
! !
RX
HDCPLINK
Front
Rear
