FAQ
Q:Noimageoraudiooutputondisplay?
A:1) Pleasecheckwhetherdisplayonstandbymode;
2) Pleasecheckwhether displayHDMI signalchannel inaccord
withHDMIinputport;
3) Pleasecheckwhether“LINK”LEDonRXsidekeepson,LED
flashmeansRXdoesnotreceivesignalfromTX;
4) Check the link lighton the TXside is normally on, ONwhen
thereisHDMIinputsignal,OFFwhenthereisnoHDMIsignal.
Q: Image unstable ?
A: 1) Please check the length button to adjust the length of the cable;
2)Pleasepull&plugCATcableoncorrespondingporttoreconnect.
Q:Onlypartialportshaveoutput?
A: 1)PleasecheckwhetherCATcableorHDMIcableconnectedcor-
rectly;
2)Pressthereceiverortransmitterbuttontore-identifythesignal;
3)Pleasepull&plugCATcableoncorrespondingporttoreconnect.
SPECIFICATION
HDMI signal HDMI1.3,compatiblewithHDCP1.2
Support resolutions 480i@60Hz,480p@60Hz,576i@50Hz,
576p@50Hz,720p@50/60Hz,
1080i@50/60Hz,1080p@50/60Hz,
Transmission distance FullHDresolution1080p@60Hz
upto40metersviaCAT6cable
IR Signal Supports20-60KHzIRdevices
EDID SupportEDIDsettingfunction
Working temperature 0°C–60°C
Power Supply DC5V/3A
Power consumption <15W
Dimensions TX:190(L)x95.9(W)x23.9(H)mm
RX:71.6x66.6x22.6mm
Color
Black
1x4 HDMI Extender Splitter
