PanEL dEscrIPtIon
1.Transmitter unit (TX)
HDMI OUT
HDMI E X TENDER
TX
HDMI E X TENDER
RX
C AT 6 / 6 A / 7 C a bl e
HDMI display
D V D
HDMI OUT
HDMI display
➎
➏
➐
➑
➊
IRsignaloutputtoconnectwithblasterextensioncable
➋
RJ45signaloutput   
➌
HDMIsignalindicatorled:itlightsonallthetimewhenHDMIsignalinput,flasheswhennosignal
input
➍
Resetbutton
➎
DC5VPowerinput
➏
HDMIsignaloutput
➐
EDIDswitch
➑
HDMIsignalinput
2. Receiver unit (RX)
HDMI OUT
HDMI E X TENDER
TX
HDMI E X TENDER
RX
C AT 6 / 6 A / 7 C a bl e
HDMI display
D V D
HDMI OUT
HDMI display
➌ ➍
➎
➏
➊
DC5Vpowerinput
➋
HDMIsignaloutput   
➌
IRsignalinputtoconnectwithIRreceiverextensioncable
➍
LENGTH:foradjustingtothelengthofnetworkcable
➎
RJ45signalinput
➏
RJ45indicatorled:itlightsonallthetimewhenHDMIsignaltransmission,flasheswhennosignal
transmission
