Techly IDATA EXT-E70POED - Package Contents; Installation Requirements

HDMI EXTENDER OVER CAT.6/7 CABLE WITH EDID
9
ENEN
IntroductIon
ThisHDMIExtenderincludesatransmitterunit(TX)andareceiverunit(RX),workingasapair.Itallows
for transmission and extension uncompressed full HD 1080p@60Hz HDMI signal via CAT6/6A/7
network cable, the transmission distance is up to 40 meters with zerolatency. It is with an EDID
switchforhelpingtosetaneededHDMIsignalformat,alsoitsupportsPoEtopowerthereceiver
(ConnectpowersupplytotheTransmitterunitonly,eachunitwillpowerup,astheReceiverunitis
poweredbytheTransmitterunitthroughnetworkcable).ThisHDMIExtendersupportIRpassback
forremotecontrolsourcedeviceeasily.ThisproductisperfectforAVtransmissioninapplicationsof
HDconferencesystem,HDvideoshooting,HDmultimediaeducationsystem,HDdigitaladvertising
and signage etc.
FEaturEs:
1.Includeatransmitterunit(TX)andareceiverunit(RX),workingasapair.
2.SupportresolutionisuptofullHD1080p@60Hz.
3.UseCAT6/6A/7forlongdistancetransmission.
4.Transmissiondistanceupto40metersviaCAT6cable.
5.Uncompressedandzerolatency.
6.WithEDIDswitchforsettingaveryneededHDMIsignalformat
7.SupportPOEtopowerthereceiverfromtransmitter.
8.SupportIRpassbackforremotecontrolsourcedevicefromreceiversiteeasily.
9.Plugandplay,withoutinstallation
PackagE contEnts
• Transmitterunitx1pc
• Receiverunitx1pc
• Powersupplyx1pc
• User‘smanualx1pc
InstaLLatIon rEQuIrEMEnts
1.HDMIsourcedevice(computergraphicscard,DVD,PS3,HDmonitoringequipmentetc).
2.HDMIdisplaydevicelikeSDTV,HDTV,andprojectorwithHDMIport.
3.NetworkcablesUTP/STPCat.5e/6networkcables,whichfollowingthestandardofEIA-568B.
