EdId sEttIng
1.HDMIsourcedevicereadstheEDIDinformationofthetransmitter(TX)andthenoutputtherelative
HDMIsignalformat.
2.Itneedstopoweronagainorresetthetransmitterunitafterre-settingEDIDeverytime.
3.When connect a TV with loop-out HDMI port of transmitter (TX), it can adjust EDID switch to
readandsavethisTV’sEDIDinformation.Whenweusethisfunction,itshouldconnectTVwith
transmitter first, and then power on these devices, so that the EDID will be read and saved
successfully. At next time, even thoughdo not connect a TV into the loop-out HDMI port, the
sourcedevicewilloutputthesavedEDIDinformationlasttime.
4.Thereare7build-inEDIDstatus,andthedefaultEDIDis720P60HzCH2.1,andotherscouldbe
selectedbytheEDIDswitchinthetransmitter,thedetailSettingInformationshownasbelow:
SwitchUP:usetheArabicnumeral“1”torepresent
SwitchDOWN:usetheArabicnumeral“0”torepresent
Switch status EDID information
Switch1 Switch2 Switch3
0 0 0 720P@50Hz2.1CH
1 0 0 720P@50Hz7.1CH
0 1 0 1080i@60Hz2.1CH
1 1 0 1080i@60Hz7.1CH
0 0 1 1080P@60Hz2.1CH
1 0 1 1080P@60Hz7.1CH
0 1 1 ReadandsavetheEDIDoftheloop-outTV
1 1 1 DefaultEDID:720P@60Hz2.1CH
FaQ
Q: No image output or audio and video display is not normal.
A:1)PressReceiver“LENGTH”buttonforadjustingthisunittoself–adapttothelengthofnetwork
cable.
Q:Receiver“LINK”ledisflashingallthetime.
A: 1)MakesurenetworkcableconnectionfollowsthestandardofEIA-568B.
 2)CheckwhetherTransmitterhasHDMIsignalinput.
 3)ResetTransmitter&Receiverandreconnect.
Q:Receiver“LINK”ledlightsonallthetimebutnoimageoutput.
A:1)PressReceiver“LENGTH”buttonforadjustingtothelengthofnetworkcable
 2)MakesureHDMIcableiswellconnectedwithTV.
 3)Makesurethenetworkcableisfinecopperwires
