Techly IDATA EXTIP-373P - Specification

HDMI EXTENDER OVER CAT.5E/6 CABLE
11
ENEN
SPECIFICATION
Power section
Voltagerange DC5V/2A
Powerconsumption TX:3.5WRX:3W
HDMI performance
and interface
HDMIcompliance HDMI1.3
HDCPcompliance HDCP1.2
HDMIresolutionsupported
480i@60Hz,480p@60Hz,576i@50Hz,
576p@50Hz,720p@50/60Hz,
1080i@50/60Hz,1080p@50/60Hz
Maximumtransferrate 10.2Gbps
InputandoutputTMDSsignal 0.5~1.5p-p(TMDS)
InputandoutputDDSsignal 5Vp-p(TTL)
Input cable lenght supported ≤5m(AWG26HDMI1.3cablestandard)
Output cable lenght supported ≤5m(AWG26HDMI1.3cablestandard)
Protection level
Electrostaticprotectionofthe
wholemachine
1aContactdischargelevel3
1bAirdischargelevel3
StandardIEC61000-4-2
Operating environment
Workingtemperature 0°C~60°C
Storage temperature -10~70°C
Humidity(nocondensation) 0~90%
Body properties
Dimension 109(P)x57.89(L)x25.50(A)mm
Material Iron alloy material
Color Black
Weight TX:130gRX:120g
Reliability MTBF 30.000ore
Maintenance:cleanonlywithadrycloth.Donotusecleaningsolventsorabrasives.
Warranty: no guarantee or liability can be accepted for any changes and modifications of the product
or damage caused due to incorrect use of this product.
IncompliancewithEUDirectiveWEEEthisproductismarkedwiththissymbol.Itmeansthat
used electrical and electronic productsshould not be mixed with general household waste.
ThereisaseparatecollectionssystemfortheseproductsincompliancewithWEEEdirective,
otherwisecontaminativeandhazardoussubstancescanpollutetheenvironment.
With the CE sign, Techly
®
 ensures that the product is conformed to the basic European
standards and directives.
