PANEL DESCRIPTION
1.Transmitter unit(TX)
➊
RJ45signaloutput   OutputencodedHDMIsignal
➋
Reset    Pressresetbuttontorestartthedevice
➌
Powerinput   ConnectwithDCSV/2Apoweradapter
➍
HDMIsignal   ConnectwithHDMIsourcedevice
2. Receiver unit (RX)
➊
R145signalinput   InputencodedHDMIsignal
➋
Reset    Pressresetbuttontorestartthedevice
➌
Powerinput   Connectforadditionalpower
➍
HDMIsignaloutput  ConnectwithHDMIdisplaydevice
INSTALLATION PROCEDURES
How to make a Cat6 network cable?
Follow the standard of EIA-568:
1-Orange/white 2-Orange  3-Green/white
4-Blue  5-Blue/white 6-Green
7-Brown/white 8-Brown
