Techly IDATA HDMI-KVM2 - Specification

EN
11
Q:Abnormal color display or flashing after all the devices are well
connected?
A:1) PlspressresetbuttonofHDMIextender.
 2) Makesurethenetworkcableismadeaccordingtothestandard
EIA-568B.
Q:USBdoesnotwork?
A:Re-install the driving software, check and make sure the USB
cablesareconnectedwell,thenresetTransmitterandReceiver.
SPECIFICATION
HDMI version HDMI1.3
HDCP version HDCP1.2
Video bandwidth ≤70Mbps
HDMI resolution
supported
640*480@60Hz,800*600@60Hz,
1024*768@60Hz,1280*720@60Hz,
1360*768@60Hz,1440*900@60Hz,
1400*1050@60Hz,1680*1050@60Hz,
1920*1080@60Hz
Audio support PCM(44.1KHz,48Khz)
HDMI connector TypeA,19-pin,female
LAN connection RJ45
Working temperature 0°C~50°C
Relative humidity 10-95%(noncondensing)
Power supply 5V/1A*2pcs
Power consumption TX<3.5wRX<3.5w
Product dimension 109x89.5x26.3mm*2pcs
Weight Tx:160gRX:170g
Color Black
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: noguaranteeorliabilitycanbeacceptedforanychanges
and modifications of the product or damage caused due to incorrect
use of this product.
IncompliancewithEUDirectiveWEEEthisproductismarked
withthis symbol. Itmeans that usedelectrical and electronic
productsshouldnotbemixedwith generalhouseholdwaste.
There is a separate collections system for these products in
compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
WiththeCEsign,Techly
®
ensures that the product is conformed
tothebasicEuropeanstandardsanddirectives.
