Audio output: Audio signal from the output port of the device, if you
want to high power play music input end connected to external power
amplifier.
HDMI signal input: this interface can be used with HD players. You
have to connect the supplied HDMI cable from your player to the
device.
Video signal cable: yellow
Left channel signal cable: white
Right channel signal cable: red
Right
channel
Video signal
cable
