Technaxx TX-168 User Manual

15
Troubleshooting
- Remote does not work:
1. Remove the small plastic strip on the top of the remote control.
2. Open the remote and check if a battery is inserted
Technical Specification
Detecting distance
~3m car interior (without obstacles (e.g. rear
wall in trucks)
Detecting range
120° cone angle
Distance IR remote control
~10m (open field)
Alarm time (Car Alarm)
120seconds maximum
Alarm volume (Car Alarm)
105dB
Alarm time (siren)
30 seconds maximum
Alarm volume (siren)
105dB (lower when mounted in engine
compartment)
USB output
DC5V / 2.4A (total)
USB-C output
DC5V / 3.0A (total)
Micro USB input
DC5V / 500mA
Battery
Built-in rechargeable 500mAh lithium
polymer battery 3.7V
Charging time
~2 hours
Working time
~7 days (by alarm once a day)
Standby time
~14 days
Input voltage (Car
Alarm)
DC12 or 24V (cigarette lighter socket)
Charging current (Car Alarm)
500mA
Operating current (Car Alarm)
600mA
Input voltage (siren)
DC12 or 24V (direct connection with car
battery)
Operating current (siren)
100mA
Remote battery
CR2032
Blade fuse siren
3A (replaceable); regular size
Cable length of siren
1.5m
Transmission frequency
2.4GHz
Frequency type
ASK
Radiated output power
maximum 15.85mW (by pressing remote
control button, not continuously)
Material
ABS
Operating temperature
-10°C – +50°C

Technaxx TX-168 Specifications

General

Type	Security management
Connectivity technology	Wired & Wireless
Product type	Car alarm system
Housing color	Black
Alarm decibels	105 dB
Operating frequency	2400 MHz
Maximum outdoor range	10 m
Input voltage	12 - 24 V
Power source type	Battery, Cygar lighter
Package type	Box
