100/1000BASE-T1 Media Converter MATEnetUser Manual

Activity LED

100 or 1000Base-T1 Ethernet data transmission.

Table 2-5 LED Description

If the GP LED is ON and Host LED is off, this indicates an error state.

The 100/1000BASE-T1 Media Converter MATEnet has LEDs integrated into the RJ-45

connector.

For RJ45 connection:

Left side:

Green = 100 BASE-TX link

Orange = 1000 BASE-T link

Right side:

Orange = ACTIVITY

2.3.1 Resetting error LED

If the error LED is lit red, a disconnection of the link can clear the LED. This can be done

by changing the DIP switch position to break the link and changing it back to form a

link again.
