Activity LED
100 or 1000Base-T1 Ethernet data transmission.
Table 2-5 LED Description
If the GP LED is ON and Host LED is off, this indicates an error state.
The 100/1000BASE-T1 Media Converter MATEnet has LEDs integrated into the RJ-45
connector.
For RJ45 connection:
Left side:
Green = 100 BASE-TX link
Orange = 1000 BASE-T link
Right side:
Orange = ACTIVITY
2.3.1 Resetting error LED
If the error LED is lit red, a disconnection of the link can clear the LED. This can be done
by changing the DIP switch position to break the link and changing it back to form a
link again.

Technica Engineering TE-1402 Specifications

General

Brand	Technica Engineering
Model	TE-1402
Category	Media Converter
Language	English
