12
1GETTING START
ED
DMS-CTC-20110713-0024 v1.0
TV LED
Upgrade LED
WPS LED
For more information about WPS, see “5.1 Connecting Your Wireless Client via WPS” on page 40.
Colour State Description
Green Solid on Set-Top Box (STB) connected to the MediaAccess Gateway
Blinking Unknown STB connected to the MediaAccess Gateway
Off No STB connected to the MediaAccess Gateway
Colour State Description
Blue Solid on Software upgrade ongoing
Off No software upgrade ongoing
Do not power off your MediaAccess Gateway or disconnect any cables as long as the Upgrade LED is on.
Interrupting the upgrade procedure may damage your MediaAccess Gateway.
Colour State Description
Green Solid On Client successfully registered via WPS
Orange Blinking WPS registration ongoing
Red Blinking Error occurred
