21
3 MANUAL INSTALLATION
DMS-CTC-20110713-0024 v1.0
Connecting the cables
Proceed as follows:
1 Take the DSL cable. This is the grey cable that is included in your box.
2 Plug one end of the cable in the grey DSL port on the back of your MediaAccess Gateway.
3 Plug the other end of the cable into the DSL/MODEM output port of your filter/splitter.
DSL
