97
8 INTERNET SECURITY
DMS-CTC-20111123-0002 v1.0
Creating your own security level
Proceed as follows:
1 In the Toolbox menu click Firewall.
2 In the Firewall section, go to the Configure page.
3 In the Pick a task list, click Create a new Security Level.
4 In the Name box, type a name for the new security level and select an existing security level to clone from.
5Click Apply.
6 A page with the firewall settings of your newly created security level appears. Click Edit.
7 Enter the following information:
The Name of the firewall rule.
The Source Interface and IP Address (range).
Or you can type a User-defined IP address (range).
The Destination Interface and IP Address (range)
Or you can type a User-defined IP address (range).
The Service type of the traffic; this can be a protocol (DNS, SMTP,...) or a specific MediaAccess Gateway system
service.
8 Select an Action that should be done on traffic for which the firewall rules applies:
Accept: to allow the traffic to pass
Deny: to drop the traffic (without notification)
Count: to let the traffic pass, but count it (Hits)
9Click Apply.
Once you create a security level, you can not delete it anymore. It will always available in the list of available security
levels.
Use Any as IP address in case all traffic for the interface should be parsed.
Use Any as IP address in case all traffic for the interface should be parsed.
