Recording from the TV
If a TV is connected to the “TV/VCR 2" terminals, you can record off
it.
Be sure to set the TV/VIDEO made on the TV to “Tv”,
Press TV/VCR 2.
'3/ Begin recording on the VCR
1.
Follow your VCR's operating instruc-
tions.
Recording from a second VCR
(VCR 2)
If a second VCR ts connected to the “TV/VCR 2” terminals, you can
record off it.
To watch the picture you are recording into VCR 1, set the TV to the
VIDEO mode.
2] Begin recording on the VCR
1.
Follow your VCR's operating instruc-
tions.
Begin playback the tape on
the VCR 2.
21
