otherwise, P=Pico-farads(pF), F=Farads (F)
* Resistance values are in ohms, unless specified otherwise, 1K=
1,000 (OHM), 1M=1,000K (OHM)
* "<IA>, <IB>, <IC>, <ID>" marks in Remarks indicate languages of
instruction manuals.
[<IA> : English, <IB> : German/Italian/French, <IC> : Spanish/
Swedish/Polish, <ID> : Netherlands / Danish]
*The markings (RTL) indicate that the Retention Time is limited for
these items. After the discontinuation of these assemblies in
production, the items will continue to be available for a specific
period of time. The retention period of availabilityis dependant on
the type of assembly, and in accordance with the laws governing
part and product retention. After the end of this period, the
assembly will no longer be available.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RHD30007-S SCREW 4
2 RKM0412B-N CABINET 1
3 XTBS3+10JFZ1 SCREW 1
4 RMZ0339 ZNR COVER 1
5 XTB3+8JFZ SCREW 3
6 REM0085 FAN UNIT 1
7 RKA0114-K FOOT 4
7-1 RKA0083-K CUSHION 4
8 XTB3+5JFZ SCREW 4
9 REE0994 FFC(19P) 1
10 RGG0173C-N FRONT PANEL 1
11 RGL0480-Q STANDBY INDICATOR 1
12 RGL0483-Q FINE TWEETER INDICATOR 1
13 RGL0494-Q VOLUME INDICATOR 1
14 RGP0774B-N SUB PANEL 1
15 RGU1856-N BUTTON,BLFS/SELECTOR 1
16 RGW0336-N VOLUME KNOB 1
17 RGW0337-N FINE TWEETER CONT.KNOB 1
18 RHD26016 SCREW 1
19 RHN90001 NUT 2
20 XTBS26+8J SCREW 7
21 SHR9806 SPACER 1
22 XTBS3+8JFZ1 SCREW 8
23 XTB3+12FFZ SCREW 1
24 XTB3+20JFZ SCREW 4
25 XTB3+6JFZ SCREW 4
26 XTW3+8T SCREW 1
27 XTW3+15T SCREW 3
28 RGN1903B-K NAME PLATE 1 (EB)
28 RGN1903A-K NAME PLATE 1 (EG)
29 REX0962 FLAT CABLE(20P)(W101) 1
To Next Page
