11
English
You can input analog audio signals to this unit and play back music.
*1 Select [BALANCED] or [UNBALANCED]. Set the analog audio input selector switch to a position that corresponds to the device you want to
play.
*2 We recommend using cables with a length of 3 m (9.9 ft) or less.
When connecting to an analog audio output device, set the input selector knob to [ANALOG]. (> 13)
To disconnect the XLR cables
Pull out the XLR cables while pressing [PUSH] at the top of the terminals.
Connecting to analog audio output devices
e.g.,
Pre-amplifier, etc.
This unit
(rear) Pre-amplifier, etc.
Audio cable
(not supplied)
XLR cable*
2
(not supplied)
*1
(11)
SE-R1-SQT0505_PP_mst.book 11 ージ 2015年1月23日 金曜日 午前9時51
