Technics SH-DV250 User Manual

Pin
No.
Mark I/O /
Division
Function
37 LED SSS O LED(SUPER
SURROUND)signal output
terminal
38 LED DPL O LED(DOLBY PRO LOGIC)
signal output terminal
39 LED
SPO
O ORANGE LED (SEAT
POSITION) signal output
terminal
40 LED
SPG
O GREEN LED (SEAT
POSITION) signal output
terminal
41 LED
3DO
O ORANGE LED (3D
ENHANCED SURROUND)
signal output terminal
42 LED
3DG
O GREEN LED (3D
ENHANCED SURROUND)
signal output terminal
43 LED
MRO
O ORANGE LED (MULTI
REAR SURROUND) signal
output terminal
44 LED
MRG
O GREEN LED (MULTI REAR
SURROUND) signal output
terminal
45 LED
VRO
O ORANGE LED (VIRTUAL
REAR SURROUND) signal
output terminal
46 LED
VRG
O GREEN LED (VIRTUAL
REAR SURROUND) signal
output terminal
47-
80
P1-P34 O Segment signal output
terminal
81 --- - Not used, open
82-
88
7G-1G O Grid signal output terminal
89 VEE I Power supply input terminal
90 CD&
DECK DI
I Data signal input terminal
(DVD and deck machanism)
91 CD&
DECK
DO
O Data signal output terminal
(DVD and deck machanism)
92 CD&
DECK
CK
I Clock signal input terminal
(DVD and deck machanism)
93 NC - Not used, open
10
