Technics SH-DV250

Ref. No. Part No. Part Name & Description Pcs Remarks
D304,05 MA719TA DIODE 2 MA2C71900A
D601-04 1SS291TA DIODE 4
D605-08 MA165 DIODE 4 MA2C165
D609,10 MA165 DIODE 2
MA2C165
D611,12 LNJ301MPUJAD LED 2
D613-17 SML79455C LED 5
D653 MA165 DIODE 1 MA2C165
D761 MA4082LTA DIODE 1
MAZ40820LF
D762 RL1N4003N02 DIODE 1
D763-66 MA165 DIODE 4 MA2C165
D767 MA4051M DIODE 1 MAZ40510M
D770 MA4062H DIODE 1
MAZ40620H
D771 MA4051-L DIODE 1 MAZ40510L
D772 MA165 DIODE 1 MA2C165
FL601 A2BD00000041 FL DISPLAY TUBE 1
IC201 NJU7313AMT2 IC 1 C0JZAS000002
IC202 NJM4558MTE1 IC 1 C0ABBB000109
IC203 BU4053BCFE2 IC 1
IC281,82 NJM4558MTE1 IC 2 C0ABBB000109
IC301 M5218AP IC 1 C0AABB000055
IC302,03 NJM4558MTE1 IC 2 C0ABBB000109
IC401 C2BBFD000246 IC 1
IC501 NJM4558MTE1 IC 1 C0ABBB000109
IC601 C2BBGF000251 IC 1
IC602 M62457AFPE1 IC 1 C1BB00000486
IC801 C2HBZC000010 IC 1
IC802 C2HBZC000008 IC 1
JK101 SJF3068-7N JACK,VDP(AUX) 1
JK102 SJF3069-5N JACK,VCR(EXT)IN/OUT 1
JK103 SJFD7 JACK,SUB WOOFER OUT 1
L101 RLBV252AV-Y COIL 1 J0JBC0000019
L301,02 RLQA3R3JT1-Y COIL 2 G0C3R3JA0019
L401 RLQB100JTD-D COIL 1
L502 RLBV252AV-Y COIL 1 J0JBC0000019
L601 RLQA100JT1-Y COIL 1 G0C100JA0019
L801 RLBV601AV-Y COIL 1 J0JCC0000077
L802 RLBV102V-Y COIL 1 J0JBC0000014
L804 RLBV102V-Y COIL 1 J0JBC0000014
L806 RLBV102V-Y COIL 1 J0JBC0000014
L807 RLL500050T-Y COIL 1 G0A100G00005
L808 RLQB100JTD-D COIL 1
L811 RLBV102V-Y COIL 1 J0JBC0000014
L814 RLL500050T-Y COIL 1 G0A100G00005
L821,22 RLBV252AV-Y COIL 2 J0JBC0000019
PCB1 REP3073D-M MAIN P.C.B.ASS’Y 1 (RTL)
Q301-04 2SC3327A TRANSISTOR 4
Q305,06 UN411FTA TRANSISTOR 2 UNR411F00A
15
