Technics SH-DV280EG

1,000 (OHM), 1M=1,000K (OHM)
*All parts are supplied by MESA.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RKA0105-K RUBBER 4
2 RKA0106-N FOOT RING 4
3 RGB0025-A TECHNICS BADGE 1
4 RGK1129-N SIDE ORNAMENT(L) 1
5 RGK1130-N SIDE ORNAMENT(R) 1
6 RGL0491-Q2 PANEL LIGHT 1
7 RGP0789L-N FRONT PANEL 1
8 RGU1862-N BUTTON BLOCK 1
9 RKW0576A-1V FL WINDOW 1
10 RGK1242-N JOG RING ORNAMENT 1
11 RGW0344-N JOG KNOB 1
12 RGW0345-N JOY KNOB 1
13 RMB0594 JOY SPRING 1
14 RMQ0882 JOY LEVER 1
15 RMQ0883 JOY SUPPORT 1
16 RMQ0884 JOY BASE 1
17 RMQ0885 JOG KNOB BASE 1
18 RMX0169 RING 1
19 XTB3+8JFZ SCREW 11
20 RHD30007-1S SCREW 4
21 RKM0400-1S CABINET 1
22 RMN0526 FL HOLDER 1
C109 ECA1CAK100XB 16V 10U 1
C131-36 ECUV1H101KCV 50V 100P 6 F1H1H101A720
C143 ECUV1H101KCV 50V 100P 1 F1H1H101A720
C201-04 ECBT1H331KB5 50V 330P 4 F1D1H331A012
C205,06 ECBT1H330J5 50V 33P 2 F1D1H330A006
C207,08 RCE1HKA4R7BG 50V 4.7U 2 F2A1H4R70009
C209,10 ECBT1C103MS5 16V 0.01U 2 F1D1C103A004
C211,12 ECBT1H104KB5 50V 0.1U 2 F1D1H1040002
C213-15 ECBT1H470J5 50V 47P 3 ECBT1H470J3
C216,17 ECBT1C103MS5 16V 0.01U 2 F1D1C103A004
C221,22 ECBA1H101KB5 50V 100P 2
C223,24 ECA1CAK100XB 16V 10U 2
C225-33 ECBA1H101KB5 50V 100P 9
C280,81 ECBT1H330J5 50V 33P 2 F1D1H330A006
C282,83 ECBA1H102KB5 50V 1000P 2
C284,85 ECBT1C103MS5 16V 0.01U 2 F1D1C103A004
C286,87 ECBT1H330J5 50V 33P 2 F1D1H330A006
C288,89 ECA1CAK100XB 16V 10U 2
C290,91 ECBT1C103MS5 16V 0.01U 2 F1D1C103A004
C301-04 RCE1HKA4R7BG 50V 4.7U 4 F2A1H4R70009
C305,06 ECBA1H101KB5 50V 100P 2
C307,08 ECBT1H100JC5 50V 10P 2 F1D1H100A015
C309,10 ECBT1C103MS5 16V 0.01U 2 F1D1C103A004
C311 ECA1CAK100XB 16V 10U 1
C312 ECA1CAK220XB 16V 22U 1
C313,14 ECA1CAK100XB 16V 10U 2
