Ref. No. Part No. Part Name & Description Pcs Remarks
IC201 AN6558F IC,PHONO EQ AMP 1
IC202 UPC4570C IC,BUFFER AMP 1
IC301-04 UPC4570C IC,TONE AMP 4
IC401-04 UPC4570C IC,TONE AMP 4
IC501 AN6558F IC,BUFFER AMP 1
IC502-04 UPC4570C IC,METER AMP 3
IC505-07 BA682A IC,LED DRIVE 3
IC601 AN6558F IC,MIC AMP 1
IC602 UPC4570C IC,AUX AMP 1
IC701,02 UPC4570C IC,MONITOR 2
IC801 M5F7815L IC,REGULATOR 1
IC802 M5F7915L IC,REGULATOR 1
IC803 M5F7812L IC,REGULATOR 1
JK101 SJF3067-2A PHONE/LINE 1
JK201 RJH2602A PHONE/LINE/MONITOR 1
JK601 RJJ63TA01 MIC 1
JK602 RJH2602A REC/LINE OUT/AUX IN 1
JK702 RJJ63TA01 HEADPHONES 1
JK801 SJS9236-1 AC INLET 1
K1 RFKVHDX1200A CROSS FADER KIT 1
K2 RFKVHDX1200B CHANNEL FADER KIT 1
L1 RLQZ371 COIL 1
P1 RPG5011 PACKING CASE 1
P2 RPN1007 CUSHION 2
P3 XZB25X34C03X POLYETHYLENE BAG 1
P4 SPP756 PROTECTION BAG 1
P5 RPH0032 PROTECTION SHEET 1
P6 RPQ0708 SPACER 1
PCB1 REP2967B-M MAIN PCB ASS'Y 1 (RTL)
PCB2 REP2968A-S VR P.C.B. ASS'Y 1 (RTL)
PCB3 REP2971A-M CONTROL P.C.B.ASS'Y 1 (RTL)
Q501-05 2SC3327A TRANSISTOR 5
Q701-04 2SC3327A TRANSISTOR 4
Q705 UN4115 TRANSISTOR 1
Q801,02 2SD2144STA TRANSISTOR 2
R101,02 ERDS2FJ102 1/4W 1K 2
R103,04 ERDS2FJ224 1/4W 220K 2
R105,06 ERDS2FJ101 1/4W 100 2
R107,08 ERDS2FJ563 1/4W 56K 2
R109,10 ERDS2FJ271 1/4W 270 2
R111,12 ERDS2FJ680 1/4W 68 2
R113,14 ERDS2FJ123 1/4W 12K 2
R115,16 ERDS2FJ184 1/4W 180K 2
R117,18 ERDS2FJ102 1/4W 1K 2
R119,20 ERDS2FJ563 1/4W 56K 2
R121-24 ERDS2FJ103 1/4W 10K 4
12
