RQT5375
9
Note:
The fader controls used in this product have a service life of
100,000 cycles. Service life will be shortened if the controls are
used in a situation that requires rapid movement of the control
lever such as during Hip-Hop transfer play. The controls may
need to be replaced frequently if they are used this way.
Two spare controls (one cross fader and one channel fader)
are provided inside the bottom panel of the unit. Please refer to
the additional instructions.
Fader replacement
Use numbers indicated in parentheses when asking for replace-
ment parts.
•Cross fader (RFKVHDX1200A)
•Channel fader (RFKVHDX1200B)
( ) INPUT control (INPUT)
( ) Input selector (LINE, PHONO)
( ) LOW-range level control (LOW)
MIC volume level control (MIC)
AUX/EFFECTOR volume level control (AUX/EFFECTOR)
MASTER volume level control (MASTER)
( ) Input sensitivity control (TRIM)
( ) HIGH-range level control (HIGH)
OUTPUT LEVEL meter (OUTPUT LEVEL)
This indicates the [LINE OUT] (L and R channels) and [MONITOR
OUT] output levels.
MONITOR volume level control (MONITOR LEVEL)
MONITOR BALANCE control (MONITOR BALANCE)
This adjusts the balance between the [LINE OUT] source and
source selected by the [MONITOR CUE] selector.
MONITOR source selector (MONITOR CUE)
Channels and can be selected as the output for headphones
or monitor speakers regardless of the position of the faders.
CROSS FADER control (CROSS FADER)
This enables the balance between the CH and CH input
levels to be adjusted.
Power button ( ON , OFF POWER)
Headphones jack (PHONES)
MIC input jack (MIC)
Power input socket (
AC IN)
( ) LINE IN connector (LINE IN)
( ) PHONO IN connector (PHONO IN)
LINE OUT connector (LINE OUT)
REC OUT connector (REC OUT)
AUX IN connector (AUX IN)
PHONO GND terminal (PHONO GND)
The grounding wire of the turntable must be secured to the
[PHONO GND] terminal in order to prevent hum and noise.
MONITOR OUT connector (MONITOR OUT)
Outputs the same signal as the headphones. Connect a monitor
amplifier when monitoring from the speakers without
headphones as in independent DJ booths. Connect the general
output amplifier to the [LINE OUT] connector .
[MONITOR BALANCE] control
Select [CUE] (completely to the right)
•Works as past general DJ mixer monitors.
•Allows the CH ( , ) input selected with the [MONITOR CUE]
control to be monitored regardless of the position of the [INPUT]
and [CROSS FADER].
Select [MASTER] (completely to the left)
•Disregards the source selected with [MONITOR CUE] ( , ).
•Allows monitoring of the output from the [LINE OUT] connector .
Select the center
•Allows the CH ( , ) input selected with the [MONITOR CUE]
control and the output from the [LINE OUT] connector to be
mixed and monitored.
To Next Page
