17.2.2 Cabinet Parts List
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0112 19P FFC WIRE [M]
2 REEX0113 21P FFC WIRE [M]
3 REEX0117 11P FFC WIRE [M]
4 RDG0267 TRAY REDUCTION GEAR [M]
5 RDG0268-1 CLOSE LOCK GEAR [M]
6 RDG0269-3 OPEN LOCK GEAR [M]
7 RDV0031 BELT [M]
8 RFKPLPD667PA TRAY MOTOR ASS’Y [M]
9 RMN0254-1 LED HOLDER [M]
10 RMN0255-2 SENSOR HOLDER [M]
11 RMN0263 MOTOR HOLDER [M]
12 REZ0648 14P FFC [M]
13 RMR0745E-K1 TRAY BASE [M]
14 RGT0019-2 ROTARY TRAY [M]
15 RHW81001-1 WASHER [M]
16 RMB0365 TRAY SPRING [M]
17 RME0152-3 LOCK GEAR SPRING [M]
18 RMS0123-1 FIXED PIN B [M]
19 XTB3+10G SCREW [M]
20 XTWS3+10S SCREW [M]
21 XWE3D13 WASHER [M]
22 RKM0339-K1 TOP CABINET [M]
23 XTB3+20J SCREW [M]
24 SNE2129-3 SCREW [M]
25 XTB3+8J SCREW [M]
26 RGR0308C-A REAR PANEL [M]P
26 RGR0308C-B REAR PANEL [M]PC
27 RMK0485 BOTTOM CHASSIS [M]
28 RMR0749-W CABLE HOLDER [M]
29 RMR0742-K TRAY BASE GUIDE L [M]
30 RMR0743-K TRAY BASE GUIDE R [M]
31 RMR0765B-H1 TRANSFORMER BASE [M]
32 RHM0001 MAGNET [M]
33 RGBX0007-K CHANGER BADGE [M]
34 RMR0744-W CLAMPER PLATE [M]
35 RMR0624-W2 CLAMPER [M]
36 RMN0185 FL HOLDER [M]
37 RGPX0028H-K FRONT PANEL [M]
38 RGUX0322-K CONTROL BUTTON [M]
39 RYQX0021-K1 PROGRAM BUTTON UNIT [M]
41 XTBS3+8JFZ1 SCREW [M]
42 RGUX0315A-K DISC BUTTON [M]
43 XTBS26+12J SCREW [M]
44 RWJ1806115XX 6P WIRE [M]
45 RMG0200 SHUTTER RUBBER [M]
47 RMR0334 FIXED PLATE [M]
