Technics SX-PC25

7.3.2. Assembly
(Step1)
Insert the front part of the key into the chassis.
(Step2)
Insert the plate spring into the hammer notch (refer to [Fig. 4] ).
(Step3)
While slowly lowering the key into the chassis, insert the plate spring into the notch at the rear of
the key (refer to [Fig. 4] ).
(Step4)
Carefully insert the key into the opening in the chassis and slide the key towards the rear to lock
it in place (refer to [Fig. 4] ).
[Fig. 4]
7
