Technics SX-PC25

7.4. Disassembly of the pedal assembly
(Step1)
Remove the pedal assembly from the pedal box.
(Step2)
Disassemble the pedal assembly (refer to [Fig. 5] )
[Fig. 5]
7.5. Removing the printed circuit boards
- Follow the item 7.1.
- Pull out the connectors on the printed circuit boards.
- ACP P.C.B.
(Step1)
Remove the 2 screws (refer to [Fig. 6] ).
8
