CONNECTIONS
A
C
D E
F
G
HB
IJ
LKM
Connections
I
US
3
B
CI CARD IN
COAX
EARPHONE
Y
Pb
Pr
VGA/PC(Audio in)
VGA/PC IN
VIDEO R
L
Earphone Earphone Input
COAX Audio Out Digital Coax Output
Video Component / Video input
YPbPr HD input (Ypbpr)
HDMI 1 HDMI input
HDMI 2 (arc) HDMI input
VGA PC VGA-PC input
VGA PC Audio In 3.5mm PC audio input
RF IN RF / TV Aerial Input
HDMI 3 HDMI input
USB USB port
CI CARD IN Common Interface module
A
I
K
M
B
J
L
C
D
E
F
G
H
L/R Audio shared for
Video/Composite and
component/ YPbPr
L/R
