1 Illustrations
1.1 Front view
20
20
17
19
18
14
12 13 15 16
2 3
1
5 64 7 8 9 10 11
1 USB port 11 INFO
2 VOLUME/ Knob 12 Track search/Backwards
3 OK/Snooze knob 13 Play/Pause
4 MUTE 14 CD slot
5 MODE/Source selection 15 Track search/Forwards
6 MENU 16 Stop
7 ALARM 17 IR receiver
8 SCAN 18 CD Eject
9 BACK 19 Display
10 PRESET 20 Stereo speakers
1.2 Rear view
21
25
26
22 23 24
21 Telescopic antenna 24 DC-IN 18 V / 3.3 A
22 Headphone connection 3.5 mm 25 Antenna connection (F)
23 AUX-In 3.5 mm 26 Wireless charging mat
