Technogel MIXTRONIC 60 - How to Unpack the Machine

4
How to unpacking the machine
MIXTRONIC 60
GROSS WEIGHT
618 Lb. 280 KG
A = 28” 720 mm.
B = 47” 1200 mm.
C = 55” 1400 mm
MIXTRONIC 110
GROSS WEIGHT
760 Lb. 345KG
A = 28” 720 mm.
B = 47” 1200 mm.
C = 55” 1400 mm
.
Remove all the wooden panels from the sides and top of case.
Lift machine with lift truck by inserting the lift blades between the
bottom of the machine and the base of the case
Unscrew the four bolts at the base of the case that hold the
machine in position from the bottom
ATTENTION:
The bottom of the case will come away after the bolts have been
removed.
After removing the base of the case, lower the. lift truck and place
the machine on the ground.
The machine may be moved using the appropriate handles.
THE TYPE OF WOOD TO BE USED FOR THE CASE IS NATURAL SPRUCE DEVOID
OF ANY CHEMICAL SUBSTANCES AND THEREFORE PERFECTLY RECYCLABLE.
