Lifting the machine
MIXTRONIC 60
Net weight
419 Lb. 190 KG
A = 400 mm.
B = 815 mm.
MIXTRONIC 110
Net weight = KG. 250
A = 520 mm.
B = 815 mm.
C = 1083 mm
.
Lift machine with a lift truck, inserting the
lift blades at the sides of
machine between the front and back wheels.
Lift machine with straps, keeping them near front and back
wheels, as in the diagram the.
The tie rod must be positioned exactly in the centre of machine.
Move machine by using the appropriate handles.
After positioning machine block the front wheel brakes with
your foot.
DO NOT USE YOUR HANDS !!
