Technical features: MIXTRONIC 110
Mechanical refrigerator
Semi-airtight power 4 HP (3 kW)
Refrigerating gas
R22 Freon (quantity 1,4. Kg)
R404 Freon (quantity 1,4. Kg)
Mixer/emulsioner
1450/2800 rev/min 0.30/0.45 kW (400V)
980/1650 rev/min 0.30/0.45 kW (220V-60hz)
Heating resistance
1 from 6 kW. and 1 from 4 kW
Glycol pump
0.48 kW monophase
Glycol (diluted to 50% with water)
7,5 litres
Condenser
water ( min. pressure 1 Bar)
Thermal magnetic calibration
200V.
50/60HZ
220V.
50HZ
220V.
60HZ
380V.
50HZ
440V.
60HZ
415V.
50HZ
Mechanical refrigerator A.
19
15.5
10.5
10.5
Mixer motor:
- low speed A.
- high speed A.
2,2
3,4
1.8
2,2
1.4
1,8
1,4
1,8
1.4
1,8
Electric system fuses
200V. and 220V.
380V. and 415V.
Heating resistance guard
3 d. 10 x 38 32A GL type
3 d. 10 x 38 20A GL type
Glycol pump guard
2 d. 10 x 38 6A AM type
2 d. 10 x 38 6A AM type
Electronic components guard
5 d. 5 x 20 2A rapid type
5 d. 5 x 20 2a rapid type
F2 primary transformer
1 d. 5 x 20 2A rapid type
1 d. 5 x 20 2A rapid type
F3 secondary transformer
2 d. x 20 6.3A delayed type
2 d. 5 x 20 6.3A delayed type
Pressure switch calibration high/low pressure
Intervention values
Low pressure release value
0.2 Bar = 2.5 Psi
High pressure release value
20 Bar = 280 Psi
Differential
0.7 Bar = 10 Psi
Thermostat calibration for glycol safety
105°C Toll. +0° - 2°C
REFRIGERATING SYSTEM WORKING PRESSURE AND TEMPERATURE
Condensation (high pressure)
Start up ( hot mixture)
End of work (cold mixture +4°C)
+35°C
95°F
0°C
32°F
-32°C
-22°F
The machine is supplied with the above mentioned values and calibrations carried out in the factory.
TECHNOGEL SPA CANNOT BE HELD LIABLE FOR DAMAGE CAUSED TO PERSONS ! DUE
TO ALTERING THE ESTABLISHED VALUES OR DUE TO USING FUSES OF THE WRONG SIZE
OR OTHER , OR ANYWAY DIFFERENT FROM THE ONES PRESCRIBED
