Technogym MB430 - Page 13

D
D
D
D
B
C
D
M10x30 IX
10.5x17.5x2.2
10x25x3 IX
16
16
16
Dual Adjustable Pulley
13
Assembling the equipment
Place the modules in a diverging position and firstly secure the upper crosspiece (B), then the
crosspiece (C), with the 16 screws (D), without tightening them.
WARNING
There are coloured indications on the crosspieces for their correct positioning.
