A
B
C
F
M
B
B
H
E
E
L
G
I
D
Dual Adjustable Pulley
7
Description of the equipment
Frames (A): the load-bearing structure of the equipment.
Crosspieces (B): elements that join the two frames.
Upper handgrips (C): held by the user to perform certain exercises.
Adjustable output cable (D): their position can be adjusted in height
with the handles (E).
Weight stack(F): each pulley, operated by the user, moves the weights
along two guides by means of a cable. A pin (G) is used for selecting the
load in order to adjust the exercise eort level.
Foothold (H): to help climb on.
Barbell support (I): optional device used to support the barbell, when
not in use.
Tray (L): used to place accessories, or anything else, during the workout.
Power mode (M): eliminates the weight stack inertia in order to perform
power and explosive strength exercises. Push the knob forward to
activate the mechanism; pull the knob back to disable it.
