18
D
E
min.
90 kg
Cables Crossed
Securing the equipment
Attach all new feet to the equipment using the screws (D) provided.
Mark the position of the holes to be drilled in the floor:
- 3 holes for the new feet;
- 2 holes for the fasteners in the frame.
Drill the holes in the floor.
Insert anchor screws (E) and screw then tightly to the floor.
