4
F
B
A
E
D
C
A
C
D
Cables Crossed
Description of the equipment
A Frame: load-bearing structure of the equipment.
B Weight stack: each pulley, i.e. high (C) or low (D), operated by the user, moves the weights along two guides by means of a cable.
A pin (E) is used for selecting the load, to adjust the exercise effort level.
F Beam: the component connecting the two frames.
