SKILLBIKE
GEAR LEVERS
The right lever changes up through the gears.
The left lever changes down through the gears.
Once you have moved the gear lever, the gear shown on the console will be updated after a
few pedal strokes.
During exercise, the noise level will vary as the gear ratio changes. It will also depend on the
number of pedal revolutions and the current gear.
When you stop pedalling, the noise level will be dierent from when you are exercising.
When you pedal backwards, the noise level will be dierent from when you pedal forwards.
Gear number I II III IV V VI VII VIII
Sprocket ratio* 36/28 36/23 36/19 36/17 52/21 52/17 52/15 52/13
Metres of development (m)** 2.85 3.48 4.04 4.60 5.41 6.61 7. 67 8.73
* Approximate equivalence.
** The measurements refer to 28” wheels.
