ITEM # PART # QTY/LIFT DESCRIPTION
85 JSJ6-08-00 2 CARRIAGE
86 X10-085 16 SLIDE BLOCKS
87 JSJ6-11 4 ARM PIN
88 JSJ4-05-ch 2 DOOR GUARD
89 X10-087 4 M8 WASHER
90 X10-088 4 M8 x 30mm Lg. SOCKET HEAD BOLT
91 X10-077 12 M10 x 25mm Lg. SOCKET HEAD BOLT
92 X10-074 12 M10 LOCK WASHER
93 JSJ6-09-07 4 INNER GEAR
94 JSJ6-13 4 ARM RESTRAINT SHAFT
95 JSJ6-14 4 ARM RESTRAINT SPRING
96 JSJ6-12 4 OUTER GEAR
97 JSJ6-09-01-00 4 FEMALE ARM WELD
98 JSJ6-09-02-00 4 MALE ARM WELD
99 JSJ4-09-08 4 M10 STOP BOLT, DOG POINT
100 X10-073 4 M10 WASHER
101 B2211 4 M6 ROLL PIN
102 B12062-12 4 FOOT PAD ASSEMBLY – 12K
103 B12568 8 M10 x 25 FLG. HEAD BOLT
104 482365 4 PAD – BOLT ON
105 B12063 4 ADAPTER PAD WELD
106 B17257 4 3 x 45mm RETAINING RING
107 B17276-1 4 ADAPTER BASE
