ITEM # PART # QTY/LIFT DESCRIPTION
JSJ6-02-02-00 1 POWER COLUMN EXTENSION
1
JSJ6-02-02-00f 1 IDLER COLUMN EXTENSION (NOT SHOWN)
2 JSJ6-03-01-00 1 OVERHEAD WELD
3 JSJ6-03-02 1 OVERHEAD SHUT OFF BAR
4 12045 1 LIMIT SWITCH
X10-060 1 M10 x 65mm BOLT, POWER COLUMN
5
X10-053 1 M10 x 45mm BOLT, IDLER COLUMN (NOT SHOWN)
6 X10-019 2 M10 NUT
7 JSJ5-03-07ch 2 CABLE TRAPPING ROD
8 X10-034 10 M6 NUT
9 JSJ4-02-18 2 HOSE GUIDE NUT
10 JSJ4-02-17 2 HOSE GUIDE
11 JSJ4-02-08 2 LOCK RELEASE SHEAVE PIN, M6
12 JSJ4-02-09 2 LOCK RELEASE SHEAVE
13 X10-032 6 M6 WASHER
JSJ4-02-11-00f 1 LOCK RELEASE SHEAVE BRACKET, POWER COLUMN
14
JSJ4-02-11-00 1 LOCK RELEASE SHEAVE BRACKET, IDLER COLUMN
15 X10-051 4 M6 x 20mm BOLT
16 X10-033 6 M6 LOCK WASHER
17 JSJ5-02-02-03 3 OVERHEAD SHUT OFF CORD CLAMP
18 X10-049 6 M5 x 8mm PAN HEAD SCREW
19 X10-037 8 M12 x 30mm BOLT
20 X10-038 8 M12 WASHER
21 X10-039 8 M12 LOCK WASHER
22 X10-040 8 M12 NUT
To Next Page
