TECHNOLIFT SL-12 - Page 12

SL-12
Installation, Operation and Maintenance
Page 12
ITEM # PART # QTY/LIFT DESCRIPTION
30 JSJ5-02-14A 2 LOCK RELEASE COVER
31 X10-065 8 M5 x 10 PHILLIPS PAN HEAD SCREW
32 JSJ5-02-12 2 LOCK RELEASE WIRE PIN
33 JSJ5-02-10 2 LOCK RELEASE CAM
34 X10-026 2 M6 x 14mm BOLT
35 JSJ5-02-03 2 LOCK PAWL
36 X10-029 2 M20 WASHER
37 JSJ5-02-07 2 LOCK RELEASE SPRING #1
38 JSJ5-02-13 2 LOCK RELEASE SPRING #2
39 JSJ5-02-04 2 LOCK RELEASE SHAFT
40 JSJ4-02-08 2 LOCK RELEASE SHEAVE PIN, M6
41 JSJ4-02-09 2 LOCK RELEASE SHEAVE
42 X10-032 2 M6 WASHER
43 X10-034 2 M6 NUT
44 JSJ5-02-06 1 LOCK RELEASE HANDLE SHAFT
45 X10-017 1 LOCK RELEASE KNOB
46 X10-037 24 M12 x 30mm BOLT
47 X10-038 24 M12 WASHER
48 X10-039 24 M12 LOCK WASHER
49 X10-040 24 M12 NUT
50 JSJ6-02-01-00F 1 IDLER COLUMN WELD
51 JSJ6-02-01-00 1 POWER COLUMN WELD
52 JSJ6-06 1 LOCK RELEASE CABLE ASSEMBLY
Order original parts when required from
GRAND PRIX IMPORT at 1-800-361-4095
