SL-12
Installation, Operation and Maintenance
Page 13
ITEM # PART # QTY/LIFT DESCRIPTION
55 JSJ6-07-00 2 HYDRAULIC CYLINDER
56 JSJ6-21 1 5/8-18 UN 90 DEGREE ELBOW
57 JSJ6-20 1 5/8-18 UN HOSE EXTENSION (18 ½” LONG)
58 JSJ6-18 1 5/8-18 UN HOSE (411” LONG)
59 JSJ6-15 1 9/16-18 UN x 9/16-18 UN x 5/8-18 UN TEE FITTING
60 JSJ5-17 1 9/16-18 UN POWER UNIT HOSE
61 JSJ4-16 1 9/16-18 UN POWER CYLINDER HOSE
62 JSJ6-19 1 9/16-18 UN 90 DEGREE ELBOW
63 X10-044 1 O-RING x 9/16-18 UN 90 DEGREE ELBOW
64 31368-19 1 POWER UNIT
Order original parts when required from
GRAND PRIX IMPORT at 1-800-361-4095
