TD20 Series VFD Function Parameters
-46-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
33: Cancel the frequency change setting temporarily
34: DC brake
35: Reserve
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Clear the power
41: Keep the power
42–60: Reserved
61: PID pole switching
62–63: Reserved
P05.10
Polarity
selection of
the input
terminals
The function code is used to set the polarity of the input
terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT8
BIT7
BIT6
BIT5
BIT4
HDI
S8
S7
S6
S5
BIT3
BIT2
BIT1
BIT0
S4
S3
S2
S1
The setting range: 0x000–0x1FF
0x000
○
P05.11
Switch filter
time
Set the sample filter time of S1–S4 and HDI terminals. If
the interference is strong, increase the parameter to
avoid wrong operation.
0.000–1.000s
0.010s
○
P05.12
Virtual
terminals
setting
0x000–0x1FF (0: Disabled, 1:Enabled )
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
0x000
◎
P05.13
Terminals
control
running mode
Set the operation mode of the terminals control
0: 2-wire control 1, comply the enable with the direction.
This mode is widely used. It determines the rotation
0
◎
