TD20 Series VFD Function Parameters
-74-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P10.31
The running
time of stage
14
Setting range of P10.(2n+1, 1<n<17): 0.0–6553.5s (min)
0.0s
○
P10.32
Multi-step
speed 15
0.0%
○
P10.33
The running
time of stage
15
0.0s
○
P10.34
Simple PLC
0–7 stage
ACC/DEC
time selection
Below is the detailed instruction:
Functio
n code
Binary bit
Step
ACC/
DEC
0
ACC/
DEC
1
ACC/
DEC
2
ACC/
DEC
3
P10.34
BIT1
BIT0
0
00
01
10
11
BIT3
BIT2
1
00
01
10
11
BIT5
BIT4
2
00
01
10
11
BIT7
BIT6
3
00
01
10
11
BIT9
BIT8
4
00
01
10
11
BIT11
BIT10
5
00
01
10
11
BIT13
BIT12
6
00
01
10
11
BIT15
BIT14
7
00
01
10
11
P10.35
BIT1
BIT0
8
00
01
10
11
BIT3
BIT2
9
00
01
10
11
BIT5
BIT4
10
00
01
10
11
BIT7
BIT6
11
00
01
10
11
BIT9
BIT8
12
00
01
10
11
BIT11
BIT10
13
00
01
10
11
BIT13
BIT12
14
00
01
10
11
BIT15
BIT14
15
00
01
10
11
0x0000
○
P10.35
Simple PLC
8–15 stage
ACC/DEC
time selection
0x0000
○
