TD20 Series VFD Function Parameters
-73-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P10.14
Multi-step
speed 6
Output frequency
t
t
t
t
t
Terminal 1
Terminal 2
Terminal 3
Terminal 4
When terminal 1= terminal 2= terminal 3= terminal
4=OFF, the frequency input manner is selected via code
P00.06 or P00.07. When all terminal 1= terminal 2=
terminal 3= terminal 4 terminals aren't off, it runs at
multi-step which takes precedence of keypad, analog
value, high-speed pulse, PLC, communication frequency
input. Select at most 16 stages speed via the
combination code of terminal 1, terminal 2, terminal 3,
and terminal 4.
The start-up and stopping of multi-step running is
determined by function code P00.06, the relationship
between terminal 1, terminal 2, terminal 3, terminal 4
terminals and multi-step speed is as following:
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
step
0
1
2
3
4
5
6
7
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
ON
ON
ON
ON
ON
ON
ON
ON
step
8
9
10
11
12
13
14
15
Setting range of P10.(2n,1<n<17): -100.0–100.0%
0.0%
○
P10.15
The running
time of stage 6
0.0s
○
P10.16
Multi-step
speed 7
0.0%
○
P10.17
The running
time of stage 7
0.0s
○
P10.18
Multi-step
speed 8
0.0%
○
P10.19
The running
time of stage 8
0.0s
○
P10.20
Multi-step
speed 9
0.0%
○
P10.21
The running
time of stage 9
0.0s
○
P10.22
Multi-step
speed 10
0.0%
○
P10.23
The running
time of stage
10
0.0s
○
P10.24
Multi-step
speed 11
0.0%
○
P10.25
The running
time of stage
11
0.0s
○
P10.26
Multi-step
speed 12
0.0%
○
P10.27
The running
time of stage
12
0.0s
○
P10.28
Multi-step
speed 13
0.0%
○
P10.29
The running
time of stage
13
0.0s
○
P10.30
Multi-step
speed 14
0.0%
○
