TD20 Series VFD Function Parameters
-81-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
3: No alarm and stop according to the stop means
(under all control modes)
P14.06
Communicatio
n processing
0x00–0x11
LED ones:
0: Write with response: the VFD will respond to all
reading and writing commands of the upper monitor.
1: Write without response: the VFD only responds to the
reading command of the upper monitor. The
communication efficiency can be increased in this mode.
LED tens: (reserved)
0: Communication encrypting is invalid
1: Communication encrypting is valid
0x00
○
P14.07
Reserved
●
P14.08
Reserved
●
P17 Group Monitoring function
P17.00
Setting
frequency
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
●
P17.01
Output
frequency
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the VFD
Range: 0.00Hz–P00.03
●
P17.03
Output voltage
Display current output voltage of the VFD
Range: 0–1200V
●
P17.04
Output current
Display current output current of the VFD
Range: 0.0–5000.0A
●
P17.05
Motor speed
Display the rotation speed of the motor.
Range: 0–65535RPM
●
P17.06
Torque current
Display current torque current of the VFD
Range: 0.0–5000.0A
●
P17.07
Magnetized
current
Display current magnetized current of the VFD
Range: 0.0–5000.0A
●
P17.08
Motor power
Display current power of the motor.
●
